Fixed Focus Lens(1.1 inch 12M pixel)
Share
หมวดหมู่ : Product Trial ,  Products ,  Fixed Focus Lens ,
Share
1.1 inch 12 million pixels compatible! !
High resolution fixed focal length lens
|Specification
Model Number | SM0818M-12MP | SM1228M-12MP | SM1628M-12MP | SM2528M-12MP | SM3528M-12MP | SM5028M-12MP |
Focus Distance | 8mm | 12mm | 16mm | 25mm | 35mm | 50mm |
Aperture Range | F2.8-C(with lock screw) | F2.8-16.0(with lock screw) | F2.8-16.0(with lock screw) | F2.8-16.0(with lock screw) | F2.8-16.0(with lock screw) | F2.8-16.0(with lock screw) |
Lens Mount | C Mount | |||||
Compatible Camera Sensor Size | 1.1 inch | |||||
Distortion(at 1″) | -4.12% | -1.79% | -1.30% | 0.40% | -0.21% | -0.05% |
Dimensions | φ56.8×54.9mm | φ47×56.99mm | φ39×48.56mm | φ38.6×44.01mm | φ39×43.96mm | φ39×46.72mm |
Weight | 236g | 186g | 146g | 133g | 119g | 134g |
Closest Distance | 0.3m | 0.1m | 0.1m | 0.15m | 0.2m | 0.3m |
Filter Screw Size | - | - | M35.5×0.5 | M35.5×0.5 | M35.5×0.5 | M35.5×0.5 |
Operating Temperature Limit | -10℃ - +50℃ |
